DESCRIPTION

Switcher: Grass Valley K-Frame-X 192×96 via ST2110
Audio Board: Calrec Argo Q Surround Sound Console
RTR Video: Lawo/Arista ST2110 Network. VSM Control, 432×528 SDI Gateway plus 24/96 4K/3G UDX and 288×96
multiviewer via IP. Additionally, up to 576×576 expandable remote IPG I/O is possible.
RTR Audio: Lawo PowerCore Audio (192×192 Analog, 384×384 AES, 36×36 MADI)
GCV T2T Fiber: YES x 2
Cameras: Up to (20) Sony HDC 5500
Replay: Up to (8) 16CH EVS XT VIA and (1) Spotbox built out in parallel SDI and ST2110 workflows
